STROBOSCOPE

A portable digital stroboscope for general laboratory use, such as speed measurement and motion studies. It emits a white light flash from a high efficiency LED solid-state light source on the front of the unit. The rear panel holds the stroboscope controls and a liquid crystal display.

The stroboscope has two modes of operation: internal oscillator and external trigger.

The internal oscillator produces a continuous flash over two frequency ranges.

The external trigger allows another frequency generating device to control the flash rate.

In addition, the stroboscope can be used as a strobe tachometer to measure speed instead of using a laser tachometer. Using a stroboscope you can “stop” the shaft down to 30 RPM (FPM).

Key features:

• Portable, lightweight, robust unit that works with selected TecQuipment products, but is also ideal for general purpose laboratory use
• High intensity 7-LED array: 4,800 Lux @ 6,000 FPM/30cm
• High efficiency LED solid-state light source with uniform flash characteristics allow for higher flash rates: 30-300,000 FPM (flashes per minute)
• Simple push-button operation with 2x and ÷2 buttons for easy adjustment
• Quartz-accuracy control system provides high accuracy: 0.02 % (± 1 digit)
• Variable flash frequency
• Includes a multi-line digital display of flash frequency
